Affordable Narrow lot Tudor house plan, mezzanine, laundry on 2nd floor, open floor plan
View the size of the rooms and height of the ceilings
|Full bathroom||9'0" x 9'4"||~ 8'0"|
|Bedroom||12'6" x 14'0"||~ 8'0"|
|Bedroom||10'8" x 9'4"||~ 8'0"|
|Bedroom||10'8" x 9'4"||~ 8'0"|
|Utility room||6'10" x 5'10"||~ 8'0"|
|Linen||1'4" x 2'0"||~ 8'0"|
|Full bathroom||5'8" x 8'0"||~ 8'0"|
|Kitchen||13'6" x 12'8"||~ 8'0"|
|Dining room||14'2" x 10'0"||~ 8'0"|
|Living room||12'6" x 16'4"||~ 15'2"|
|Foyer||7'4" x 8'0"||~ 8'0"|
|Garage||12'6" x 20'0"||~ 9'8"|
|Porch||8'6" x 3'4"||N/A|
|Deck||14'2" x 4'8"||N/A|
|Total living area||1584 sq.ft.|
|1st level||764 sq.ft.|
|2nd level||820 sq.ft.|
|Ridge height from top of foundation||32'8"|
|Exterior wall||2 X 6|
|Foundation type included in the plan||Full Basement|
|Other available foundations (a fee may apply)||Floating Slab, Crawl space, Monolithic Slab|
|Builder price code||D|
|Garage type||One-car garage (276 sq.ft.)|
|Living bonus space||-|
