House plan Pinson (2695)
Mediteranean style house plan,open floor plan, central fireplace, laundry room, master suite, computer area
View the size of the rooms and height of the ceilings
| 2nd level | ||
|---|---|---|
| Rooms | Sizes | Ceiling |
| Full bathroom | 8'10" x 6'0" | ~ 9'0" |
| Master suite | 12'4" x 15'4" | ~ 9'2" |
| Bedroom | 12'4" x 13'0" | ~ 8'0" |
| Bedroom | 12'0" x 10'0" | ~ 8'0" |
| Den | 8'0" x 9'8" | ~ 8'0" |
| 1st level | ||
|---|---|---|
| Rooms | Sizes | Ceiling |
| Kitchen | 12'4" x 12'2" | ~ 9'0" |
| Dining room | 12'4" x 15'4" | ~ 9'0" |
| Living room | 16'4" x 17'4" | ~ 9'0" |
| Foyer | 9'8" x 9'8" | ~ 9'0" |
| Half bath or powder room | 6'2" x 8'2" | ~ 9'0" |
| Garage | 24'8" x 20'8" | ~ 10'8" |
| Utility room | 9'0" x 6'2" | ~ 9'0" |
| Porch | 10'0" x 12'0" | N/A |
| Porch | 14'4" x 5'0" | N/A |
General specifications
| Total living area | 2233 sq.ft. |
| 2nd level | 1081 sq.ft. |
| 1st level | 1152 sq.ft. |
| Width | 43'8" |
| Depth | 50'8" |
| Ridge height from top of foundation | 25'6" |
| Exterior wall | 2 X 6 |
| Foundation type included in the plan | Unfinished Basement i |
| Other available foundations (a fee may apply) | Floating Slab, Crawl space, Monolithic Slab |
| Builder price code | F |
Rooms specifications
Other useful information on this plan
Spacious mediterranean style home
.
Distinctive elements
9Ft ceiling on all of main level. Three-sided fireplace shared between family and dining rooms. Lots of windows at rear for plenty of natural daylight. Large family room with false beams on ceiling. Three good-sized rooms on second level.
Plan feature(s)
Fireplace, Lunch counter, Gound floor laundry room, Ceiling over 8', Cathedral ceiling, Master suite upstairs, Walk-in master bed., Separate bath and shower, Double sinks, Planning desk
Plan architectural style(s)
. Mediterranean, . Florida, . American, . Vacation and waterfront
