3 to 4 bedroom mediteranean luxury villa house plan, 3 car garage, split bedroom floor plan, 2 fireplaces
View the size of the rooms and height of the ceilings
|Kitchen||14'8" x 16'0"||~ 10'2"|
|Living room||21'4" x 18'2"||~ 11'2"|
|Dining room||12'0" x 15'0"||~ 10'2"|
|Foyer||10'4" x 10'0"||~ 13'2"|
|Half bath or powder room||4'10" x 9'8"||~ 10'2"|
|Master suite||17'8" x 22'8"||~ 11'2"|
|Full bathroom||9'0" x 6'0"||~ 10'2"|
|Great room or Family room||19'4" x 20'8"||~ 10'2"|
|Bedroom||11'0" x 12'2"||~ 10'2"|
|Bedroom||11'0" x 12'2"||~ 10'2"|
|Utility room||11'6" x 11'8"||~ 10'2"|
|Storage||5'4" x 7'8"||~ 10'2"|
|Garage||21'0" x 30'0"||~ 10'6"|
|Home office||12'4" x 10'0"||~ 10'2"|
|Dinette||7'0" x 9'4"||~ 10'2"|
|Storage||8'8" x 6'0"||~ 10'6"|
|Porch||52'0" x 14'0"||N/A|
|Porch||9'8" x 4'4"||N/A|
|Total living area||3667 sq.ft.|
|1st level||3667 sq.ft.|
|Ridge height from top of foundation||25'4"|
|Exterior wall||2 X 6|
|Foundation type included in the plan||Monolithic Slab|
|Other available foundations (a fee may apply)||Floating Slab, Crawl space|
|Builder price code||J|
|Garage type||Three-car garage (756 sq.ft.)|
|Living bonus space||-|
