Mediterranean style house plan, 4 bedrooms, 3-car garage, master suite with private balcony
View the size of the rooms and height of the ceilings
|Dining room||12'0" x 17'0"||~ 9'0"|
|Living room||15'0" x 17'0"||~ 9'0"|
|Utility room||13'8" x 8'10"||~ 9'0"|
|Half bath or powder room||4'4" x 5'4"||~ 9'0"|
|Kitchen||11'0" x 19'0"||~ 9'0"|
|Foyer||6'4" x 5'0"||~ 20'2"|
|Garage||20'4" x 25'2"||~ 8'10"|
|Porch||14'0" x 5'0"||N/A|
|Porch||23'0" x 12'0"||N/A|
|Office||10'2" x 10'10"||~ 9'0"|
|Full bathroom||10'2" x 5'4"||~ 8'0"|
|Playroom||12'0" x 11'4"||~ 8'0"|
|Master suite||12'0" x 16'0"||~ 8'0"|
|Bedroom||13'8" x 11'0"||~ 8'0"|
|Bedroom||13'8" x 11'4"||~ 8'0"|
|Bonus storage||12'0" x 23'4"||~ 7'0"|
|Balcony||23'0" x 12'0"||N/A|
|Total living area||2427 sq.ft.|
|1st level||1260 sq.ft.|
|2nd level||1167 sq.ft.|
|Ridge height from top of foundation||31'9"|
|Exterior wall||Block , 2 X 6|
|Foundation type included in the plan||Floating Slab|
|Other available foundations (a fee may apply)||Crawl space, Monolithic Slab|
|Builder price code||F|
|Garage type||Two-car garage (532 sq.ft.)|
|Living bonus space||-|
|Bonus storage||282 pi2|
