Tudor house plan with garage, 3 large bedrooms, open floor concept, laundry room on main floor
View the size of the rooms and height of the ceilings
|Full bathroom||15'4" x 7'0"||~ 8'0"|
|Bedroom||11'0" x 12'0"||~ 8'0"|
|Bedroom||10'4" x 10'4"||~ 8'0"|
|Bedroom||15'4" x 10'2"||~ 8'0"|
|Kitchen||10'0" x 12'0"||~ 8'0"|
|Dining room||20'4" x 15'10"||~ 8'0"|
|Foyer||3'10" x 5'0"||~ 8'0"|
|Utility room||9'0" x 6'0"||~ 8'0"|
|Garage||15'4" x 19'8"||~ 10'8"|
|Porch||8'0" x 6'4"||N/A|
|Porch||6'4" x 4'0"||N/A|
|Total living area||1534 sq.ft.|
|1st level||669 sq.ft.|
|2nd level||865 sq.ft.|
|Ridge height from top of foundation||31'6"|
|Exterior wall||2 X 6|
|Foundation type included in the plan||Full Basement|
|Other available foundations (a fee may apply)||Floating Slab, Crawl space, Monolithic Slab|
|Builder price code||D|
|Garage type||One-car garage (336 sq.ft.)|
|Living bonus space||-|
