House plan Tamblyn (3317)
Affordable 2 bedroom Modern Cubic shaped house plan, split-level contemporary house plan with fireplace
View the size of the rooms and height of the ceilings
| 1st level | ||
|---|---|---|
| Rooms | Sizes | Ceiling |
| Kitchen | 18'4" x 13'0" | ~ 8'0" |
| Living room | 13'0" x 14'4" | ~ 8'0" |
| Foyer | 10'0" x 4'8" | ~ 12'4" |
| Full bathroom | 8'8" x 12'10" | ~ 8'0" |
| Bedroom | 12'0" x 14'0" | ~ 8'0" |
| Bedroom | 12'0" x 11'6" | ~ 8'0" |
| Porch | 10'4" x 4'2" | N/A |
| Porch | 10'0" x 5'0" | N/A |
General specifications
| Total living area | 1210 sq.ft. |
| 1st level | 1210 sq.ft. |
| Width | 32'0" |
| Depth | 44'0" |
| Ridge height from top of foundation | 18'8" |
| Exterior wall | 2 X 6 |
| Foundation type included in the plan | Unfinished Basement i |
| Other available foundations (a fee may apply) | Monolithic Slab |
| Builder price code | C |
Rooms specifications
Other useful information on this plan
Small Modern Cube Shaped House Plan
Beautifully simple geometric lines define this stately home. A split entry creates a dramatic 12’ foyer and to greet guests. Upstairs, we discover an open living room warmed by a fireplace. The area is open to the kitchen and dining areas for a modern open-concept feel. An ample kitchen island provides space for socializing and light meals. Sliding doors allow for easy access of outdoor dining or recreation.
Two bedrooms share a bathroom between, thus keeping each room more private.
A undeveloped basement provides the option for further development of living or storage areas.
Distinctive elements
Remarkable front entry with 12' ceiling. Fireplace in the living room. Triple patio doors in the dining room. Cornered fenestration in the kitchen and central island. Built-ins in the living room, the dining room and in the master suite. Bathroom with toilet area apart, independent shower and laundry space.
Plan feature(s)
Fireplace, Gound floor laundry room, Island, Separate bath and shower
Plan architectural style(s)
. Modern / Design, . Contemporary, . Transitional
