3 bedroom manor style house plan, ideal for narrow lot , garage and great master suite
View the size of the rooms and height of the ceilings
|Full bathroom||7'6" x 5'0"||~ 8'0"|
|Master suite||13'0" x 12'6"||~ 8'0"|
|Bedroom||10'10" x 11'0"||~ 8'0"|
|Bedroom||10'10" x 9'8"||~ 8'0"|
|Storage||1'4" x 7'4"||~ 8'0"|
|Kitchen||16'2" x 10'6"||~ 8'0"|
|Dining room||15'0" x 23'0"||~ 8'0"|
|Foyer||8'8" x 6'6"||~ 8'0"|
|Half bath or powder room||5'6" x 10'6"||~ 8'0"|
|Garage||12'0" x 25'0"||~ 10'6"|
|Closet||2'0" x 6'6"||~ 8'0"|
|Porch||3'6" x 8'0"||N/A|
|Porch||4'0" x 10'8"||N/A|
|Total living area||1733 sq.ft.|
|1st level||881 sq.ft.|
|2nd level||852 sq.ft.|
|Ridge height from top of foundation||38'8"|
|Exterior wall||2 X 6|
|Foundation type included in the plan||Full Basement|
|Builder price code||D|
|Garage type||One-car garage (335 sq.ft.)|
|Living bonus space||-|
