Abbot 2 (4096)
Duplex house plan with 2 bedroom per unit, kitchen with lunch counter, open floor plan
View the size of the rooms and height of the ceilings
| 1st level | ||
|---|---|---|
| Rooms | Sizes | Ceiling |
| Full bathroom | 10'2" x 7'4" | ~ 8'0" |
| Kitchen | 8'0" x 12'8" | ~ 8'0" |
| Dining room | 9'0" x 14'4" | ~ 8'0" |
| Living room | 13'10" x 8'0" | ~ 8'0" |
| Bedroom | 11'0" x 12'0" | ~ 8'0" |
| Closet | 2'0" x 8'10" | ~ 8'0" |
| Bedroom | 10'0" x 11'4" | ~ 8'0" |
| Closet | 2'0" x 5'8" | ~ 8'0" |
| Closet | 2'0" x 2'10" | ~ 8'0" |
| Covered porch | 5'0" x 3'0" | N/A |
| Covered deck | 8'0" x 5'0" | N/A |
| Storage | 4'10" x 3'0" | ~ 8'0" |
| Covered porch | 5'0" x 3'0" | N/A |
| 2nd level | ||
|---|---|---|
| Rooms | Sizes | Ceiling |
| Dining room | 9'0" x 12'8" | ~ 8'0" |
| Living room | 14'4" x 16'6" | ~ 8'0" |
| Closet | 2'0" x 5'2" | ~ 8'0" |
| Balcony | 12'0" x 12'0" | N/A |
| Storage | 3'4" x 3'10" | ~ 8'0" |
| Storage | 7'3" x 3'2" | ~ 8'0" |
| Bathroom/laundry room | 10'4" x 7'4" | ~ 8'0" |
| Kitchen | 8'0" x 12'8" | ~ 8'0" |
| Bedroom | 11'0" x 12'0" | ~ 8'0" |
| Closet | 2'0" x 8'10" | ~ 8'0" |
| Bedroom | 10'0" x 11'2" | ~ 8'0" |
| Closet | 2'0" x 8'10" | ~ 8'0" |
General specifications
| Total living area | 2136 sq.ft. |
| 1st level | 1065 sq.ft. |
| 2nd level | 1071 sq.ft. |
| Width | 32'0" |
| Depth | 33'8" |
| Ridge height from top of foundation | 29'2" |
| Exterior wall | 2 X 6 |
| Foundation type included in the plan | Full Basement i |
| Other available foundations (a fee may apply) | Floating Slab, Crawl space, Monolithic Slab |
| Builder price code | MB |
Rooms specifications
Units specifications
Other useful information on this plan
Affordable duplex house plan with 2 bedrooms per unit
Ideal as a revenue property or mortgage helper, duplexes allow you to get on the first step of the property ladder. This lovely duplex would be right at home in any neighbourhood, looking like a typical single-family dwelling.
The floor plan is echoed on each level with slight variations due to stair placement. Each unit offers every comfort including storage, great living areas, two bedrooms and a balcony or patio. The main level unit also benefits from additional basement space which could be developed to suit.
When financing a house for only yourself, a revenue suite may be just the solution to getting ahead!
Distinctive elements
Covered front stoops, basement belongs to Unit 1, abundant fenestration.
The bath is 5' long.
Plan feature(s)
Panoramic view, Deck, Open floor layout
Plan architectural style(s)
. Country, . Traditional
