Génération 2 (3299-V1)
Generational house plan with 3 bedrooms and 2 baths in main apartment
Bedrooms
3, 4
Bathroom(s)
3
Living area
2440 sq.ft.
Garage type
Two-car garage
front - BASE MODEL
Left view
Rear view - BASE MODEL
Rear view - BASE MODEL
interior view
interior view
interior view
View by floor
-
1st level
| 1st level | ||||
| Rooms | Sizes | Ceiling | ||
| Garage | 24'0" x 24'4" | ~ 9'0" | ||
| Covered porch | 6'8" x 4'0" | ~ 9'4" | ||
| Covered porch | 24'0" x 4'0" | ~ 9'4" | ||
| Covered deck | 16'0" x 12'0" | ~ 9'4" | ||
| Master suite | 12'8" x 13'6" | ~ 9'0" | ||
| Walk-in closet | 6'2" x 3'6" | ~ 9'0" | ||
| Walk-in closet | 6'2" x 3'6" | ~ 9'0" | ||
| Full bathroom | 9'8" x 11'4" | ~ 9'0" | ||
| Shower | 5'0" x 3'0" | ~ 0'0" | ||
| Linen | 3'0" x 1'4" | ~ 0'0" | ||
| Storage room | 2'0" x 5'8" | ~ 9'0" | ||
| Laundry room | 7'0" x 5'8" | ~ 9'0" | ||
| Kitchen | 9'8" x 14'0" | ~ 9'0" | ||
| Pantry | 9'4" x 7'4" | ~ 9'0" | ||
| Kitchen island | 4'4" x 6'0" | ~ 0'0" | ||
| Dining room | 10'4" x 16'0" | ~ 9'0" | ||
| Bedroom | 12'8" x 10'0" | ~ 9'0" | ||
| Bedroom | 12'8" x 11'4" | ~ 9'0" | ||
| Living room | 17'8" x 12'0" | ~ 9'0" | ||
| Kitchen/dining room | 9'10" x 13'4" | ~ 9'0" | ||
| Living room | 9'4" x 16'4" | ~ 9'0" | ||
| Foyer | 6'6" x 5'0" | ~ 9'0" | ||
| Closet | 2'0" x 5'0" | ~ 9'0" | ||
| Full bathroom | 14'10" x 5'0" | ~ 9'0" | ||
| Shower | 3'0" x 5'0" | ~ 0'0" | ||
| Linen | 2'0" x 1'6" | ~ 0'0" | ||
| Storage | 1'8" x 3'0" | ~ 9'0" | ||
| Master suite | 11'2" x 10'0" | ~ 9'0" | ||
| Walk-in closet | 5'6" x 6'0" | ~ 9'0" | ||
| Mechanical room | 6'2" x 5'0" | ~ 9'0" | ||
| Jack and Jills | 5'4" x 8'6" | ~ 9'0" | ||
| Shower | 5'0" x 3'0" | ~ 0'0" | ||
| Walk-in closet | 7'0" x 8'6" | ~ 9'0" | ||
| Total living area | 2440 sq.ft. |
| 1st level | 2440 sq.ft. |
| Width | 70'0" |
| Depth | 60'0" |
| Ridge height from top of foundation | 26'4" |
| Exterior wall | 2 X 6 |
| Foundation type included in the plan | Floating Slab i |
Activity sector
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Bathroom
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Bathroom
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Kitchen
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Bedroom
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Bedroom
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Dining room
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Sitting room
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Sitting room
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Activity sector
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Activity sector
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Activity sector
Photos represent a modified version of the original plan and are not available for sale. We invite you to get your free plan modification cost estimate if you would like any changes to the original plan.
Description
Ground floor Main apartment: Entrance, kitchen, dining room, living room, master suite, 2 secondary bedrooms with Jill & Jack bathroom, laundry room. Grand-parents' apartment: Entrance, kitchen, dining and living room, main bedroom, storage. Sheltered rear terrace accessible from both appartments. House proposed on floating slab. Other types of foundation available, please contact our customer service.
Other useful information on this plan
Distinctive elements
Bi-generation Farmhouse style house plan with double garage.
9 'ceiling throughout.
Floating slab foundation, other types of foundation available.
Parents' lodging with 3 bedrooms and 2 bathrooms.
The 2 apartments share the laundry room & pantry.
Parents bedroom with double walk-in closet and access to the semi-private bathroom.
Bedrooms 2 and 3 share a walk-in closet and shower room (Jack & Jill).
All family spaces are open plan.
A 16 'x 12' sheltered patio is accessible from both units.
Access to grandparents' accommodation through the garage.
